GE IS215ACLEH1C Thermocouple output module

The first VMEbus slave image will have the base and bound register set to 640 KB by the BIOS. For example: VMEbus Slave Image 0: BS= 0000000h BD= A0000h TO = 0000000h The second VMEbus slave image will have the base register set to be contiguous with the bound register from the first VMEbus Slave image by the BIOS. The bound register is limited by the total XVME-660 DRAM. The translation offset register is offset by 384 KB, which is equivalent to the A0000h-FFFFFh range on the XVME-660 board.

The XVME-660 DRAM memory is based on the PC architecture and is not contiguous.

 The VMEbus slave images may be set up to allow this DRAM to appear as one contiguous block. Mapping defined by the PC architecture can be overcome if the VMEbus slave image window is always configured with a 1 MB translation offset. From a user and software standpoint, this is desirable because the interrupt vector table, system parameters, and communication buffers (keyboard) are placed in low DRAM. This provides more system protection.
