VMIC ZT5524A1A Axial displacement module

Product introduction

VMIC ZT5524A1A Axial displacement module

ZT5524A1A restriction on address configuration relating to each 1 Mbyte boundary for the 512 K and 256 K option Reflective Memory Boards. Even though the 512 K option may be mapped on any 512 K boundary, relative to the 1 Mbyte boundaries, there is an upper and a lower position (see Figure 3.5-1). All boards must be mapped to the same position relative to 1 Mbyte boundaries. There are four positions possible with the 256 K Reflective Memory Boards relative to 1 Mbyte boundaries. All 256 K boards on the link must be mapped to the same position relative to the 1 Mbyte boundaries in order to communicate. There is no restriction between which 1 Mbyte boundary each board is on. Exact address matching is not required; only the position relative to the nearest 1 Mbyte boundary must be the same.

 Nodes may be intermixed in any order as far as unique board IDs are concerned. There is parity and other error checking hardware on the link so the Reflective Memory Board will inform the user if an improper condition in the link exists. Each Reflective Memory Board may be mapped into a different address space. Data will appear in the same location in each node relative to the base 1 Mbyte boundry each Reflective Memory is mapped to.
