NI PXI-6122 Industrial Control Module Card

Classify：Industry news |Time：2023-06-30 14:01:05

Product Details Introduction

NI PXI-6122 is an industrial control module card mainly used for data acquisition and control applications. The following are the main features and functions of this module:

High performance data acquisition: PXI-6122 has high-speed data acquisition function, which can collect analog and digital data from external signal sources at high sampling rates. It has fast data transmission and high resolution, which can meet applications with high requirements for fast changing signals and accuracy.

Multi channel input/output: This module provides multiple input and output channels, which can simultaneously collect and generate multiple signals. Usually, it provides 16 or more analog input channels and digital I/O channels to meet the needs of multi-channel data acquisition and control.

Flexible triggering and synchronization functions: PXI-6122 supports multiple triggering modes and synchronization functions, and can be triggered externally, software, or internally as needed. This enables the module to synchronize with other devices, achieving highly accurate time correlation and data synchronization.

High precision measurement and generation: This module provides high-precision analog input and output with low noise and distortion characteristics. It can accurately measure the amplitude, frequency, and phase of the input signal, while generating accurate analog output signals.

Real time control and rapid response: PXI-6122 has real-time control capability, which can quickly respond to external input and trigger signals, achieving real-time data collection and control. This makes it suitable for applications that require high-speed response and real-time adjustment, such as real-time testing and feedback control systems.

Software support: The NI PXI-6122 module is equipped with powerful software support, including NI-DAQmx driver and LabVIEW programming environment. These tools and interfaces enable users to easily configure, control, and analyze data, improving the efficiency of development and debugging.

Product image

NI PXI-6122.jpg
