TRICONEX AI3351 Analog input card application

TRICONEX AI3351 Analog input card application

Always turn off the power before installing or removing modules: - Failing to turn off the power supply when installing or removing modules, may result in damage. z Do not touch components in the module: - In some modules you can remove the right-side cover and install ROM packs or change switch settings. While doing this, do not touch any components on the printed-circuit board, otherwise components may be damaged and modules may fail to work. z Do not use unused terminals: - Do not connect wires to unused terminals on a terminal block or in a connector. Doing so may adversely affect the functions of the module. z Use the following power source:- Use only F3PUxx-xx as the power supply module. - If using this product as a UL-approved product, for the external power supply, use a limited voltage / current circuit power source or a Class 2 power source.- Refer to the hardware user’s manual or the applicable user’s manual for the external wiring drawing. - Refer to “A3.6.5 Connecting Output Devices” in the hardware user’s manual before connecting the wiring for the output signal. - Refer to “A3.5.4 Grounding Procedure” in the hardware user’s manual for attaching the grounding wiring.

Waste Electrical and Electronic Equipment

Waste Electrical and Electronic Equipment (WEEE), Directive 2002/96/EC (This directive is only valid in the EU.) This product complies with the WEEE Directive (2002/96/EC) marking requirement. The following marking indicates that you must not discard this electrical/electronic product in domestic household waste. Product Category With reference to the equipment types in the WEEE directive Annex 1, this product is classified as a “Monitoring and Control instrumentation” product. Do not dispose in domestic household waste. When disposing products in the EU, contact your local Yokogawa Europe B. V. office.

How to Discard Batteries

The following description on DIRECTIVE 2006/66/EC (hereinafter referred to as the EU new directive on batteries) is valid only in the European Union. Some models of this product contain batteries that cannot be removed by the user. Make sure to dispose of the batteries along with the product. Do not dispose in domestic household waste. When disposing products in the EU, contact your local Yokogawa Europe B. V. office. Battery type: Lithium battery Note: The symbol above means that the battery must be collected separately as specified in Annex II of the EU new directive on batteries.
