IC698CPE030 Gas turbine module industry application

IC698CPE030 Gas turbine module industry application

Two indicators at the top of the front panel of the Engineering Card indicate the operational status of the card: 3.2.1 - Green LED A continuously illuminated LED indicates that the correct dc power is connected to the rack via the DC Input Card. A flashing LED at approximately two second intervals, indicates a low dc power input level. A flashing LED at approximately 0.5 second intervals, indicates a hardware fault.The Engineering Card push-buttons control various functions depending on the type of control card fitted and whether the Engineering Key is fitted.When the up push-button ( ) is operated, it increases the value of those functions that can be adjusted.

Provides an indication

 of the operation of the Engineering Card communications status as follows: Off: Engineering Card functioning correctly and the engineering functions are locked. Operators functions are operational to allow the checking of various control card settings. On: Engineering Card functioning correctly and the engineering functions are unlocked enabling changes to be made to the operation of a selected control card. Flashing: Indicates that a control card has been withdrawn from the rack, there is a communications error or that an external PC running the engineering interface software is communicating with the control cards. Note: To reset this indication, insert the Engineering Key briefly and remove it again.

4 Operation of the Up and Down Push-buttons Simultaneously

 This operation can only be used if a serial printer is connected to the rack. When the up ( ) and down ( ) push-buttons are operated simultaneously a print out command is selected of the control card configuration and status. 3.3.5 Accept Push-button ( ) When the accept push-button ( ) is operated during any of the engineers functions, this button confirms adjustments that have been made and then cancels that function. 3.3.6 Reject Push-button ( ) When operated during any of the engineers functions and providing the accept ( ) push-button has not been operated, the reject push-button ( ) cancels adjustments that have been made. This push-button is also used to deselect a selected function.

THE Main products

PLC programmable controller module, DCS card, ESD system card, vibration monitoring system card, steam turbine control system module, gas generator spare parts, etc. Advantage brands: Allen Bradley, BentlyNevada, ABB, Emerson Overseas, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft and other imported industrial parts

The products are widely used in metallurgy, oil and gas, glass manufacturing, aluminum, petrochemical, coal mine, paper and printing, textile printing, machinery, electronic manufacturing, automobile manufacturing, plastic machinery, power, water conservancy, water treatment/environmental protection, boiler heating, energy, power transmission and distribution, etc
