PDD500A101 3BHE037649R0101 process control card

PDD500A101 3BHE037649R0101 process control card

Two cabinets are available, an 8-way to accommodate the 8-way front access rack and a 16-way to accommodate the 16-way front access rack. The cabinet must be secured to a wall, or other suitable vertical surface, as follows: (1) Knock out the bottom gland-plate entries as appropriate for the system cabling and fit the glands before mounting the cabinet. (2) Attach the four mounting brackets provided to the cabinet. (3) Using the dimensions shown mark the position of the mounting holes on the mounting surface. (4) Drill and wall plug the mounting holes as necessary. Note: The mounting brackets will accept up to a 10mm diameter screw. (5) Secure the cabinet in position using appropriate mounting screws. (6) Fit the System 57 Rack and AC to DC Power Supply Unit (if required) into the cabinet in the positions shown. (7) Pass cables through the gland adjacent to field terminal blocks, where possible keeping the sensor cable(s) separate from the other wiring.

Prepare and connect the cable ends

to Field Interface and Relay Card terminals leaving sufficient cable length to allow for the rack to be withdrawn if future expansion is required. For terminal identification see Chapter 2. (9) Ensure that the cabinet is properly earthed by connecting a suitable earth cable to the earth stud located in the bottom panel of the cabinet. (10) Close and lock the cabinet.Insert the rack into the aperture and secure using M6, or similar bolts, through the four mounting holes located upon the front flange plates.Ensure adequate support at the rear of rear access racks.Prepare and connect the cable ends to Field Interface and Relay Cards terminals. For terminal identification see Chapter 2. Where possible keep sensor cables separate from the other wiring. Ensure that the rack is properly earthed by connecting a suitable earth cable to the earth stud located at the rear of the rack.

RACK INSTALLATION

The 16-way 3U high rear access and 6U high front access racks are suitable for mounting in standard 19" (483mm) wide Mounting Frames. These are fitted as follows: (1) Insert the rack into the 19" Mounting Frame and secure using M6 or similar bolts through the four mounting holes located on the front flange plates. (2) Ensure adequate support at the rear of rear access racks. (3) Prepare and connect the cable ends to Field Interface and Relay Card terminals. For terminal identification see Chapter 2. Where possible keep sensor cables separate from the other wiring. (4) Ensure that the rack is properly earthed by connecting a suitable earth cable to the earth stud located at the rear of the rack.
