LD800HSEEX 3BSE073314R1 Controller Module
LD800HSEEX 3BSE073314R1 Controller Module
Product Details Introduction
ABB LD800HSE EX (model: 3BSE073314R1) is a FOUNDATION Fieldbus (FF) linking device used to connect FF high-speed Ethernet (HSE) and H1 devices, commonly used in process automation and industrial control systems. This device supports four independent H1 links and one HSE connector, suitable for DIN rail installation, and has ATEX and IECEx Zone 2 hazardous area certification.
main features
communication interface
1 10BASE-T/100BASE-TX Ethernet port (auto sensing)
Four 31.25 kbit/s H1 fieldbus interfaces
Complies with FF HSE Class 42c standard and supports redundant configuration
Power requirements
Working voltage: 24 V DC (± 20%)
Typical current consumption: 200 mA
Power consumption: approximately 4.8 W
Environmental adaptability
Working temperature range: 0 ° C to+55 ° C
Storage temperature range:- 20 ° C to+70 ° C
Relative humidity: 0% to 95% (without condensation)
Installation and Structure
Suitable for 35mm DIN rail installation
Horizontal installation is required to ensure good ventilation
Suitable for hazardous areas (compliant with ATEX and IECEx Zone 2 standards)
The design of LD800HSE EX meets the high reliability requirements of industrial automation, ensuring stable communication connections in harsh environments. It is widely used in industries such as process control, petrochemicals, pharmaceuticals, and energy.
Product imag
