560PSU02 1KGT011900R0001 Input Coupling Unit Module
560PSU02 1KGT011900R0001 Input Coupling Unit Module
Product Details Introduction
560PSU02 1KGT011900R0001 "is an input coupling unit module designed by ABB for its power automation system, commonly used for power interface management of control systems such as RTU560.
Here are some detailed information about the module:
Basic Product Information
Product model: 560PSU02
Ordering Code: 1KGT011900R0001
manufacturer: ABB（Asea Brown Boveri）
Series: RTU560 Control System/Substation Automation
Function and purpose
The main functions of the 560PSU02 input coupling unit include:
Input power distribution: Introduce and distribute power from the main power source (such as DC 24V or DC 48V) to various modules of the RTU system (such as CPU, I/O modules, etc.)
Electrical isolation protection: By using optocouplers or relays, the input signal is electrically isolated to improve system stability and anti-interference ability
Grounding protection: Provide a grounding interface to ensure that the equipment complies with industrial safety standards
Status indication: equipped with LED indicator lights, real-time display of module working status (such as whether the power supply is normal)
Redundancy support: Some versions support redundant power access to enhance system reliability
Technical parameters (reference)
Parameter item description
Input voltage range 24V DC/48V DC (depending on actual configuration)
Isolation method: optocoupler or transformer isolation
Module installation method: DIN rail installation (standard ABB 560 control system slot)
Size compatible with RTU560 rack, typically with 3U module size
Working environment temperature range -25 ° C to+70 ° C
Communication interfaces are usually not available (used for power or signal coupling)
Product imag
