NI PXI-6225 Multifunctional Data Acquisition Module

Product Details Introduction

NI PXI-6225 is a multifunctional data acquisition module with the following main functions:

High precision data acquisition: The NI PXI-6225 adopts a high-precision analog-to-digital converter (ADC), which can achieve high-resolution analog signal acquisition. It supports different sampling rate and resolution options to meet various application requirements.

Multi channel input: This module provides multiple analog input channels and can simultaneously collect multiple analog signals. Each channel has independent configuration and control capabilities, allowing for single ended or differential input.

Multiple input ranges: The NI PXI-6225 supports multiple input range options and can adapt to analog signals of different amplitudes. Users can choose an appropriate input range based on specific application requirements.

Digital Input/Output: In addition to analog inputs, this module also provides digital input/output (DIO) functionality. It has multiple digital input and output channels, which can read and generate digital signals for communication and control with digital devices.

High speed sampling and output: The NI PXI-6225 supports high-speed data acquisition and output, enabling data reading and writing at high sampling rates. This makes it suitable for applications that require real-time response and high-speed data processing.

Flexible triggering and synchronization: This module has flexible triggering and synchronization functions, which can control data collection and output through external triggering signals or software triggering. At the same time, it also supports synchronization operations with other devices.

Software support and programming interfaces: NI PXI-6225 is equipped with rich software support and programming interfaces, including LabVIEW, C/C++, Python, and more. This allows users to easily configure, control, and analyze data.

Product image
