NI PXIE-4331 781345-01 Strain/Bridge Input Module

Product Details Introduction

NI PXIe-4331 is a strain/bridge input module, model 781345-01. The following is a general introduction to the product:

NI PXIe-4331 is a high-precision, high-speed strain/bridge input module designed to measure signals from strain sensors and bridge sensors. It is part of the PXIE platform provided by National Instruments (NI) for analog input and data collection applications.

This module has the following main features and functions:

High precision measurement: The NI PXIe-4331 module provides high-precision strain/bridge measurement capabilities. It can measure small bridge signals and strain sensor signals, and provide accurate measurement results.

High speed collection: This module supports high-speed data collection and can obtain a large number of data points in a short period of time. This makes it suitable for high-speed sampling and real-time control applications.

Multi channel input: The PXIe-4331 module has multiple channels and can simultaneously measure multiple strain sensors or bridge sensors. This can facilitate multi-channel strain measurement or multi-point monitoring.

Built in signal conditioning: This module has a built-in signal conditioning circuit that can amplify, filter, and linearize the corresponding signal. This simplifies the requirements for external signal conditioning circuits and improves the overall performance of the system.

Software support: The NI PXIE-4331 module is compatible with software tools such as NI-DAQmx driver and LabVIEW, providing rich software support. This allows users to easily configure and control modules, as well as perform data analysis and visualization.

PXI Express interface: This module adopts the PXI Express interface and has high-speed data transmission and flexible system integration capabilities. It can seamlessly integrate with other PXIE modules and devices to build complex measurement and control systems.

Product image
