NI PXI-6122 Multifunctional Data Acquisition Module

Product Details Introduction

NI PXI-6122 is a high-performance multifunctional data acquisition module with the following functional features:

High speed sampling rate: The module supports high-speed data collection and can achieve a continuous sampling rate of up to 2 MS/s. This makes it suitable for applications that require high-speed data acquisition, such as vibration analysis, audio testing, etc.

High resolution: The module has a 16 bit ADC (analog-to-digital converter) resolution, which can provide high-precision signal measurement and acquisition.

Multi channel input: The PXI-6122 module has multiple input channels and supports multi-channel parallel acquisition. This allows for the simultaneous collection of data from multiple signal sources, facilitating multi-channel data analysis and processing.

Software programmability: The module can be used in conjunction with NI-DAQmx drivers and LabVIEW software tools, providing strong programmability and flexibility. Users can configure modules, collect data, and process data through software.

Multiple triggering modes: The module supports multiple triggering modes, including software triggering, hardware triggering, and external triggering. This allows for flexible control of the triggering conditions for data collection based on actual needs.

Supporting software tools: The NI PXI-6122 module comes with NI-DAQmx driver and LabVIEW software tools, providing rich data collection, analysis, and visualization functions. Users can use these tools for data processing, drawing, and report generation operations.

PXI platform compatibility: The module adopts PXI bus interface, which has good compatibility and can seamlessly integrate with other PXI modules and devices to build complex measurement and control systems.

Product image
