NI PXI-6143 Control Pulse Card Module

Product Details Introduction

NI PXI-6143 is a control pulse card module belonging to the PXI series of National Instruments (NI). The following is the product introduction of this module:

NI PXI-6143 is a high-performance, multi-channel control pulse card module that can be used to measure and generate accurate pulse signals. This module has the following main features and functions:

Number of channels: The NI PXI-6143 module provides multiple input and output channels, and the specific number of channels depends on the specific model and configuration. Each channel can receive and send pulse signals.

Input function: This module can receive external pulse signals and provide high-precision time measurement and counting functions. It supports various input level ranges and triggering modes to meet different application requirements.

Output function: The PXI-6143 module can generate precise pulse signals for controlling external devices or triggering other system operations. It supports various output level ranges and trigger modes to meet various application requirements.

High precision and fast response: This module has high-precision pulse measurement and generation capabilities, which can achieve microsecond level time resolution and fast response time.

Flexible configuration and programming: The NI PXI-6143 module can be used in conjunction with the driver software and programming tools provided by National Instruments (NI) to achieve flexible system configuration and programming control. Users can configure and control the functions of the module through programming interfaces, and interact with other devices for data.

PXI interface: This module adopts PXI interface and can seamlessly integrate with other PXI modules and devices to build complex measurement and control systems. It also supports PXI bus synchronization and triggering functions to achieve synchronous operation of multiple modules.

Product image
