IC697CPM790-GD Gas turbine module

IV. Measurements:
R phase summation current
S phase summation current
T phase summation current
R phase restraint current
S phase restraint current
T phase restraint current.InrushRatio Ratio of 2nd. harmonic current content to fundamental current above which an inrush condition is detected. InrushTime Time during which the inrush detection function is active following initial energisation or an external fault. a1 Amplitude compensation factor for winding 1. s1 Circuit of winding 1 (primary). Settings provided:
Y: Y-connected
D: delta-connected CurrentInp1 defines the current input channel for winding 1. The first channel (R phase) of three phases must be specified. a2 Amplitude compensation factor for winding 2. s2 Group of connection for winding 2. Settings provided: All usual groups of connection with
designation of the circuit (y = star, d = delta, z = zigzag)
phase-angle adjustment of the winding 2 voltage in relation to the winding 1 voltage in multiples of 30°.

Explanation of parameters
