PPD113 PPD103B101 3BHE020455R0101 High-speed processor and patented technology for faster throughput ▪ Universal backplane that supports two different backplane busses per module slot: o High-speed, PCI-based for fast throughput of new advanced I/O o Serial backplane for PPD113 PPD103B101 3BHE020455R0101  serial modules and easy migration of Series 90-30™ I/O

▪ Memory for ladder logic documentation and machine documentation in the controller to reduce downtime and improve troubleshooting ▪ Open communications support ▪ Variety of discrete, analog, and special-purpose modules

▪ PPD113 PPD103B101 3BHE020455R0101 Hot insertion in both the PCI Backplane and Serial Backplane for new and migrated I/O modules. Refer to Hot Insertion and Removal, Section 2.6.4.1. ▪ Isolated 24 Vdc terminal for I/O modules and a grounding bar that reduces user wiringPPD113 PPD103B101 3BHE020455R0101

Programming and Configuration PACSystems equipment is configured and programmed using PAC Machine Edition (PME) software. PME features a common user interface across product families and drag-and-drop editing. PME also includes a built-in Web server for real-time data delivery during system operation.
