The main products

Spare parts spare parts, the DCS control system of PLC system and the robot system spare parts,Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts

Products are widely used in metallurgy, petroleum, glass, aluminum manufacturing, petrochemical industry, coal mine, papermaking, printing, textile printing and dyeing, machinery, electronics, automobile manufacturing, tobacco, plastics machinery, electric power, water conservancy, water treatment/environmental protection, municipal engineering, boiler heating, energy, power transmission and distribution and so on.

1C31166G01 analog output module

The TUG 4 is a protection relay for separate two-step protection of up to 16 measuring inputs. Included functions are conversion of measured values of dc signals from generator/prime mover , protective functions for temperature (two levels of alarm/monitoring), and 4 relay outputs for user configuration.The UMT 1 is a digital multi measuring transducer that measures true rms via three-phase measuring of voltage and current. Three analog outputs - 20/0/4–+20 mA and an analog output manager offers the flexibility to output every measured and calculated value. The impulse output can be configured to output kWh/h or kVARh/h

The ST 2 Lambda Control is a digital Lambda control used to achieve low exhaust emission values in gas powered machines. The Lambda voltage is directly measured and evaluated in the ST 2. The regulating signals given to the gas regulating path may for instance be transmitted via a stepper motor or an analog output. The IKD 1 is an external I/O expansion board. If the digital inputs and outputs in the controller are not sufficient, 8 digital inputs and outputs can be connected via the CAN bus with this extension card. It is possible to connect two IKD 1 to the controller in parallel.

Discrete-Function Controls and Accessories

To complete your power management system, Woodward offers the most complete range of analog and digital controls available in the industry. The GW 4 is an extension to many of the GCP genset control units, providing the communications interface from the GCP network to a variety of external buses. Available communication buses include RS-232, RS-485, Modbus, Profibus, the Leonhard-Data-Protocol, and even an external modem. All the secondary interface/bus systems receive/send data from/to the Guidance Level CAN bus network used for the GCP Series. Upon request, more protocols will be available.The LS 4 is a power circuit breaker control for complex applications where additional section switches (such as bus-couplers) exist. The measurement value logging and the "switch-in-order" for the power circuit breakers are put into effect in the LS 4. The set value for the synchronization is transmitted from the LS 4 via the CAN bus to the genset controller (such as GCP).The IKN 1 is an external 20 channel NiCrNi temperature scanner. It is an Intelligent Terminal NiCrNi to measure up to 20 different temperatures, including mean-value generation and limit-value monitoring. The measured data is transmitted via the CAN bus to the controller, where they can be displayed. Configuration via CAN bus is also possible.

The Real Power Sensor

is a solid-state electronic device housed in a metal chassis intended for installation in a prime mover control cabinet. The unit contains its own power supply and is powered separately from the speed control. The Real Power Sensor constantly monitors the generator output voltage and current with transformers. These transformers are selected to provide potential voltage of 115 Vac or 230 Vac at nominal generator voltage. The current transformers are selected to provide a 5- amp secondary current at full generator output. The Real Power Sensor provides a signal to the speed control that is proportional to the output power of the generator. The Real Power Sensor is used with Woodward speed controls to measure generator output power and provide a kilowatt signal to the speed control.The Digital Reference Unit generates a precise voltage that may be used wherever a very accurate reference signal is required. Typical use combines the Digital Reference Unit with other Woodward controls for regulation of speed or load. This device provides precise electronic control of the reference-signal voltage. The level of the reference signal can be manually or automatically selected from maximum to minimum with an additional adjustable intermediate set point.
