CI867K01 3BSE043660R1 processor module

This board is used for communications to DCS 500 converter modules equipped with software version up to S21.1xx. It consists of 3 different communication channels. All RxD channels (receiver) have blue color, all TxD channels (transmitter) have grey color. If any connections should be made always connect the same color with each other (plug and socket) . Channel 1 is a HDLC channel of 1.5 Mbits/s and is used for the communication with a PC. Channel 2 cannot be used together with software version S21.xxx. Channel 3 is a DDCS channel of up to 4 Mbits/s and is used if a serial link based on PROFIBUS hardware, CS31 hardware or MODBUS hardware should be realized. If one of these possibilities should be used an adaptation module is needed. Please refer to the documentation which is available for the link system needed.The SDCS-AMC-DC and the SDCS-AMC-DC Classic boards are identical except the assembly of optical components for channel 0 and 2.

This board must be used together

 with a DCS 600 module equipped with a SDCS-CON-2 board including software S15.xxx. The board is equipped with an own controller with the following main functionalities: • The software structure implemented in this board is divided in two sections. The first section is built from the speed regulator and its additional functions which is producing the torque reference. • The second section is prepared to be programmed with its own characteristics for control and regulation. • Evaluation of the received data to produce a torque reference to be transmitted to the controller board CON-2. Actual values from the CON-2 are read, evaluated and retransmitted to the overriding control. Furthermore the board is equipped with three optical channels (max. data transmission speed is 4 Mb for each optical channel): - Channel 0 is used to communicate data from the overriding control (APC2 or via adapter modules from other controllers) to the DCS600-drive. - Channel 2 (Master-Follower) is used to operate two or more drives dependent on each other. Commands and values needed for this application are produced on this board. - Channel 3 is prepared to connect the PC tool for commissioning and maintenance

DDCS Branching unit NDBU-95

DDCS Branching Unit (DBU) is used (only for DCS 600/DCF 600) to implement the star topology of DDCS link. This allows a slave unit to fail or become unpowered without disabling the communication. The NDBU receives messages from the master (PC) and sends them to all the slave units simultaneously. Each slave unit has an individual address and only the addressed slave unit sends a reply message to the master. It is also possible to use NDBU thus enabling peer-to-peer communication NDBU-95 DDCS Branching Unit has nine output channels where messages from the master are sent. The reply message sent by one slave unit is delivered to the master and it can be delivered also to other slaves if necessary. Several NDBU-95s can be used in parallel, in series or in any combination of these. The maximum distance between the master and NDBU-95 as well as between two NDBU-95s, see manual 3ADW000100R0201.
