Nikon 4S017-107 Analog/Digital Conversion Card

Nikon 4S017-107 Analog/Digital Conversion Card

Product Details Introduction

Analog to Digital Converter (ADC) is a hardware device used to convert analog signals into digital signals or digital signals into analog signals. The following are some common features of analog/digital conversion cards:

Analog Input/Digital Output (ADC): ADC cards are used to convert analog signals (such as voltage, current, or temperature) into digital form, so that computers or control systems can process and analyze these data.

Digital Input/Analog Output (DAC): DAC cards are used to convert digital signals into analog signals for controlling analog devices, motors, sensors, etc.

Resolution: Analog/digital conversion cards often have different resolution options to indicate how many discrete values they can divide the analog signal into. The higher the resolution, the more accurate the converted digital signal.

Sampling rate: The sampling rate represents the speed at which an analog signal is converted into a digital signal. A higher sampling rate allows for faster data capture, but also requires greater storage and computing power.

Number of channels: Analog/digital conversion cards typically support multiple input or output channels, allowing for simultaneous processing of multiple signal sources.

Precision: Precision represents the accuracy of the digital output signal. Higher accuracy usually means less error and more accurate signal output.

Voltage range: This refers to the maximum and minimum voltage values of the analog input signal. Analog/digital conversion cards typically support multiple voltage ranges to meet the needs of different applications.

Input impedance: Input impedance is the resistance of an analog input signal, usually measured in ohms (Ω). Appropriate input impedance ensures accurate signal acquisition.

Output range: For DAC cards, the output range refers to the maximum and minimum output values of the analog signal.

Software support: Analog/digital conversion cards are usually equipped with corresponding software drivers and support libraries for communication and configuration with computers or embedded systems.

Application areas: These cards are widely used in various fields, including audio processing, communication systems, medical equipment, instruments and meters, industrial control, etc.

Product image
