Nikon 4S017-656 Backplane Interface Board

Nikon 4S017-656 Backplane Interface Board

Product Details Introduction

The Nikon 4S017-656 Backplane Interface Board is an electronic board that typically has the following product features and functions:

Slot support: The Nikon 4S017-656 backplane interface board typically contains multiple slots for inserting and installing other modular electronic cards, such as communication cards, processor cards, storage cards, I/O cards, etc.

Electrical connections: These slots provide electrical connections, allowing power, data, and control signals to be shared between slot cards and backplane interface boards, as well as between different slot cards.

High bandwidth communication: The Nikon 4S017-656 backplane interface board typically supports high bandwidth data transmission to meet applications that require a large amount of data exchange, such as high-performance computing or data centers.

Multiple communication interfaces: They provide various communication interfaces, including Ethernet ports, serial ports, USB, PCI Express, InfiniBand, etc., to connect to various communication and data devices.

Scalability: The design of the Nikon 4S017-656 backplane interface board typically allows for system scalability, allowing users to add or replace slot cards as needed to adapt to different application needs.

Hot swapping support: Some backplane interface boards have the function of supporting hot swapping, allowing users to insert or remove slot cards while the system is running without having to shut down the entire system.

Physical support: They provide physical support for slot cards to prevent damage under vibration or impact.

Power Management: The Nikon 4S017-656 backplane interface board typically includes power management circuitry to ensure that slot cards receive appropriate power supply.

Data routing and distribution: They have data routing and distribution functions, which can assist in data exchange and communication between slot cards.

Redundancy support: The Nikon 4S017-656 backplane interface board supports redundant design to improve system reliability.

Product image
