PPCC322BE HIEE300900R0001 control module

System Controller The system controller handles the entire data transfer between the various components of the module: ƒ Safety-related processor system ƒ System busses A and B ƒ Ethernet switch with connected interfaces The module has a RAM and a non-volatile memory. The non-volatile memory is protected by a CRC. The non-volatile memory contains the following programs and information: ƒ Operating System ƒ User project ƒ Enable switch, watchdog time, safety time ƒ Online modifications ƒ Variable with the RETAIN attribute ƒ Production data and, if necessary, trimming data ƒ Fault status history ƒ Events While booting, the system transfers the program code from the non-volatile memory to the redundant program and data memory.

Alarms and Events

The processor module records alarms and other events in its non-volatile memory. Events are state changes of a variable that are performed by the plant or controllers and are provided with a timestamp. Alarms are events that signalize an increasing risk potential. The HIMax system records the state changes as events specifying the time point when they occurred. The X-OPC server transfers the events to other systems such as control systems, that display or evaluate the events. HIMax differentiate between Boolean and scalar events.

Boolean Events:

ƒ Changes of Boolean variables, e.g., of digital inputs. ƒ Alarm and normal state: They can be arbitrarily assigned to the variable states. Scalar Events: ƒ Exceedance of the limit values defined for a scalar variable. ƒ Scalar variables have a numeric data type e.g., INT, REAL. ƒ Two upper limits and two lower limits are possible. ƒ For the limit values, the following condition must be met: Highest limit ≥ upper limit ≥ normal area ≥ lower limit ≥ lowest limit. ƒ An hysteresis can be effective in the following cases: - If the value falls below the upper limit. - If the value exceeds the lower limit. An hysteresis is defined to avoid a needless large number of events when a global variable strongly oscillate around a limit. The processor module can only create events if they are configured in SILworX, see Chapter 4.1.5.
