3BHB004661R0001 Printed Circuit Board

3BHB004661R0001 Printed Circuit Board

Product Details Introduction

3BHB004661R0001 Printed Circuit Board (PCB) is an important electronic component used to connect and support electronic components, achieving electrical connections between circuits. It is an indispensable component of modern electronic devices, widely used in various industries, communications, medical, aerospace and other fields.

The following are some main features and functions of 3BHB004661R0001 printed circuit board:

Substrate: Printed circuit boards usually use insulating materials as substrates, such as glass fiber, polyimide, etc. These materials have good insulation performance and mechanical strength, which can support electronic components and prevent electrical short circuits.

Conductive circuit: A conductive circuit is made on a substrate through printing, etching, and other processes. These circuits are usually made of metal (such as copper) and are used to connect electronic components and achieve electrical connections between circuits.

Component support: The conductive wires and pads on the printed circuit board are used to fix and support electronic components. Connect the components to the conductive wires on the circuit board through welding or other connection methods.

Multilayer structure: In order to improve the performance and functionality of the circuit board, 3BHB004661R0001 printed circuit board may adopt a multi-layer structure. The multi-layer structure achieves more complex circuit connections and higher electrical performance by adding insulation and conductive layers between substrates.

Surface treatment: In order to improve the reliability and aesthetics of circuit boards, the surface of printed circuit boards is usually treated, such as coating solder mask layer, gold plating, etc. These treatments can protect conductive circuits from corrosion and oxidation, and improve the lifespan of circuit boards.

Product image
