Product Details Introduction

The 57160001-BH connection unit is a component of the ABB Advant controller 400 series. It is a communication module designed to provide connections between the Advant controller 400 and other devices in the control system. This connection unit has two communication ports: one for the main network and the other for the auxiliary network.

The following are the detailed features of the 57160001-BH connection unit:

Communication protocol support: This connection unit supports multiple communication protocols, including MODBUS, DNP3, and IEC 60870-5-101/104. This enables it to communicate with various types of devices.

Redundancy function: The 57160001-BH connection unit has built-in redundancy function to improve system reliability. For example, it supports dual port communication and automatic switching between networks, ensuring that in the event of a port or network failure, the other can take over the operation.

Installation and Connection: This connection unit is designed to be installed in a standard 19 inch rack for easy system integration and installation. In addition, it can be connected to the Advant controller 400 through ribbon cables, simplifying the wiring process.

Power requirement: The 57160001-BH connection unit requires an external power source to supply power. This ensures its stable operation and continuous communication capability.

Status indicator: In order to facilitate user monitoring of the operation status of the module, this connection unit is equipped with a status indicator light. These indicator lights can display the working status, communication status, or other important information of the module.

In summary, the 57160001-BH connection unit is a key component in the ABB Advant Controller 400 series, providing powerful communication capabilities and redundant functionality to ensure reliable communication and collaboration among devices in the control system. For industrial automation applications that require integration of multiple devices and systems, this is a very useful component.

Product image
