57120001-HP Connection Unit Module

57120001-HP Connection Unit Module

Product Details Introduction

The 57120001-HP connection unit module is an analog board connection device produced by ABB, mainly used in ABB Advant OCS and ABB Advant S100 I/O systems. This connection unit module has 31 PT 100.3 line interfaces, which can easily connect various sensors and actuators to achieve signal transmission and control.

Here are some detailed information about the 57120001-HP connection unit module:

Product number and model: The product number of this module is 57120001-HP, and ABB's model is DSTA 145.

Size and weight: The module measures 4.0 inches x 1.0 inches x 10.0 inches (10.2 centimeters x 2.5 centimeters x 25.4 centimeters) and weighs 0 pounds 6.1 ounces (0.2 kilograms). This makes it suitable for installation in various standard industrial automation cabinets.

Origin: The origin of this connecting unit module is Sweden, representing ABB's global leading position in industrial automation.

Application field: The 57120001-HP connection unit module is mainly used in ABB Advanced OCS process control systems. Although ABB Advance OCS has been discontinued, many old systems are still in use, and this connection unit module provides necessary expansion and connection functions for these systems. In addition, it can also be used with ABB Advance S100 I/O modules to achieve digital input/output functionality.

Features and advantages: The connection unit module is compact in design, with rich interfaces, and can easily connect multiple sensors and actuators. Meanwhile, it adopts ABB's advanced technology to ensure stable signal transmission and high reliability. This is very important for industrial automation systems that require long-term continuous operation.

Installation and Use: When installing and using the 57120001-HP connection unit module, it is recommended that users refer to the technical documentation and user manual provided by ABB. These documents provide detailed installation steps, configuration methods, and troubleshooting guides to help users quickly and accurately complete module installation and configuration work.

In summary, the 57120001-HP connection unit module is an indispensable part of the ABB Advant OCS and ABB Advant S100 I/O systems, providing stable and reliable connection functions to ensure the normal operation of industrial automation systems.

Product image
