UNS2880B-P,V1 3BHE014967R0001 DCS module

Flash Memory ƒ Type: NOR flash, on-board programmable c Capacity: 128MB c Write Protection: Hardware via switch, software via register or sector lock ƒ Type: NAND flash, on-board programmable c Capacity: 4GB or 8GB c Write Protection: Software via register c Supported by YAFFS (Linux) or Datalight FlashFX® Pro (VxWorks) under separate license Non-volatile Memory ƒ Type: SEEPROM, on-board programmable c Capacity: 128KB (available for users), 8KB baseboard Vital Product Data (VPD), and two (2) 256B Serial Presence Detect (SPD) ƒ Type: MRAM c Capacity: 512KB VMEbus Interface ƒ Compliance: ANSI/VITA 1-1994 VME64 (IEEE STD 1014), ANSI/VITA 1.1-1997 VME64 Extensions, VITA 1.5-199x 2eSST ƒ Controller: Tundra Tsi148 PCI-X to VMEbus bridge with support for VME64 and 2eSST protocols ƒ DTB Master: A16, A24, A32, A64; D08-D64, SCT, BLT, MBLT, 2eVME, 2eSST ƒ DTB Slave: A16, A24, A32, A64; D08-D64, SCT, BLT, MBLT, 2eVME, 2eSST, UAT ƒ Arbiter: RR/PRI ƒ Interrupt Handler/Generator: IRQ 1-7/Any one of seven IRQs ƒ System Controller: Yes, switchable or auto detect ƒ Location Monitor: Two, LMA32

Ethernet Interface

ƒ Controller: MPC864xD Triple Speed (TSEC) Ethernet Controllers ƒ Interface Speed: Four @ 10/100/1000Mbps (TSEC) ƒ Connector: Two Gigabit Ethernet ports routed to front panel RJ-45, two Gigabit Ethernet ports to VMEbus P2 connector, pin out matching MVME7216E RTM ƒ Indicators: Link status/speed/activity Asynchronous Serial Ports ƒ Port 1 c Controller: MPC864xD Duart (second port N/C) c Number of Ports: One 16550 compatible c Configuration: RS-232 DTE (RxD, TxD, RTS, CTS) c Async Baud Rate, bps max.: 38.4K RS-232, 115Kbps raw c Connector: One front panel Mini DB-9 c Mini DB-9 to DB-9 adapter cable: SERIAL-MINI-D2 ƒ Ports 2-5 c Controller: Exar ST16C544D Quart c Number of Ports: Four 16550 compatible c Configuration: RS-232 (RxD, TxD, RTS, CTS) c Async Baud Rate, b/s max: 38.4K RS-232, 115Kbps raw c Connector: Via VMEbus P2 connector, pinout matching MVME7216E RTM

Counters/Timers

 ƒ TOD Clock Device: Maxim DS1375 I2C device with battery backup ƒ Cell Storage Life: 10 years at 25 °C ƒ Cell Capacity Life: One year at 100% duty cycle, 25 °C ƒ Removable Battery: Yes ƒ Real-Time Timers/Counters: Four, 32-bit programmable timers in PLD; four, 32-bit programmable/ cascadable timers in MPC864xD ƒ Watchdog Timer: In PLD Other Features ƒ RoHS compliant ƒ Jumper-less configuration ƒ On-board temperature sensor (Maxim MAX6649) ƒ JTAG header for connection of diagnostic tools Front Panel ƒ IEEE or Scanbe handles ƒ Connectors for serial, Gigabit Ethernet and USB ports (commercial temperature only) ƒ Openings for PMC sites All printed wiring boards (PWBs) are manufactured with a flammability rating of 94V-0 by UL recognized manufacturers.
