Bently3500/50 speed module

Bently3500/50 speed module

Product Details Introduction

The Bently 3500/50 Speed Module is a device used for industrial automation control, specifically used in the Bently Nevada 3500 monitoring system. The following is a detailed introduction about the speed module:

Function and features:

The Bently 3500/50 Speed Module is a two channel module that can accept signals from eddy current sensors or magnetic sensors to determine the speed of the shaft or the acceleration of the rotor.

It compares the measured speed or rotor acceleration with the user programmable alarm point and issues an alarm when it exceeds the alarm point.

This module can be programmed using 3500 rack configuration software and can be configured into three different types as needed: speed monitoring, set point alarm, and speed band alarm; Speed monitoring, set point alarm, and zero speed indication; Speed monitoring, set point alarm, and rotor acceleration alarm.

The Bently 3500/50 speed module also has a peak holding function, which can store the highest speed that the machine has ever reached and be reset by the user.

Input and output parameters:

The input signal range is usually+10.0 V to -24.0 V.

The input impedance may be 20 k Ω (standard), 40 k Ω (TMR), or 7.15 k Ω (internal barrier) depending on the configuration.

The power consumption is 5.8 watts (typical value).

The output impedance is 550 Ω.

The front panel LED indicators may include OK, TX/RX, Bypass, etc.

Application field:

The Bently 3500/50 speed module is widely used in various industrial fields, such as power plants, petrochemical plants, metallurgical plants, etc., to monitor and control the operating status of mechanical equipment, such as vibration monitoring and mechanical equipment protection systems.

Overall, the Bently 3500/50 speed module is a powerful and stable industrial automation control equipment that can meet the needs of various complex industrial environments.

Product image
