BENTLY 3500/42M 176449-02 Vibration Axial Displacement Card

BENTLY 3500/42M 176449-02 Vibration Axial Displacement Card

Product Details Introduction

BENTLY 3500/42M 176449-02 is a vibration and axial displacement monitoring card, mainly used for vibration and axial displacement monitoring of industrial equipment. The features of this card include:

Multi functional monitoring: This card can be configured as a 4-channel monitoring module for various parameters such as radial vibration, axial displacement, eccentricity, REBAM (metal temperature of rotor radial bearings), and differential expansion measurement.

Input type: This card only accepts the input type of eddy current sensors, which are commonly used to measure the vibration and displacement of rotating machinery.

Additional features: In addition to basic vibration and displacement monitoring functions, this card can also receive speed, acceleration, and dual probe (speed and displacement) input types and their related signal adjustments, such as filtering and integration. It can also perform differential signal processing, extract casing vibration signals from relative shaft vibration, and provide absolute measurement information for certain large gas and steam turbines.

T ü V certification: This card has T ü V certification, indicating that it complies with relevant safety and quality standards.

When using the BENTLY 3500/42M 176449-02 vibration axial displacement card, the following points should be noted:

Installation location: Ensure that the card is installed in a location that is easy to access and maintain for daily inspection and maintenance.

Sensor connection: It should be ensured that the connection between the sensor and the card is correct and reliable to avoid signal interference and measurement errors.

Cable laying: Bentley extension cables are the intermediate components connecting probes and proximitors, and their installation should ensure that they are not easily damaged during use and that signal transmission is normal and reliable. When laying cables, relevant electrical installation specifications should be followed.

Product image
