Product Details Introduction

The AB 1794-ACNR15XT/D adapter module is a product under Allen Bradley Automation and belongs to the Flex I/O ControlNet adapter module. Here are some detailed features and applications of the adapter module:

Communication Interface: The AB 1794-ACNR15XT/D adapter module has various communication interfaces, such as ControlNet, DeviceNet, etc., allowing it to easily connect to the fieldbus network, achieve data exchange with other devices and controllers, and transmit control instructions.

Module Expansion: This adapter module has the function of module expansion and can be connected to other I/O modules or devices to expand the input and output capacity of the control system. This makes it flexible to apply in large-scale industrial control systems.

Place of use: This adapter module is specially approved for use in hazardous areas where steam, mist, and gases are unlikely to occur frequently. When connecting and disconnecting, it is necessary to pay attention to the connection status of the power supply and module to avoid accidents in hazardous areas.

Physical specifications: The AB 1794-ACNR15XT/D adapter module has a size of 87.4 x 94 x 92 millimeters and weighs approximately 220 grams. In addition, it also complies with T4A North American temperature codes as well as T4 ATEX and IECEx temperature codes.

Electrical specifications: The peak power consumption of this module is 3.4 watts at a voltage of 19.2 volts DC. For power connections, solid/twisted copper wire of 22 to 12 AWG should be used, and ensure that the terminal screw torque does not exceed 7 pounds per inch.

Cable and Connection: The recommended communication cable is the Baitong RG-6/U cable, with Class 3 wires used for power ports and Class 2 wires used for communication ports.

Status indication: Indicators are provided on the module to display the status of two communication ports and I/O status, making it convenient for users to monitor the working status of the module in real time.

Overall, the AB 1794-ACNR15XT/D adapter module plays an important role in industrial control systems, providing strong support for industrial automation through its powerful communication and expansion functions.

Product image
