Product Details Introduction

The 3BHE013299R0002 processor module is an industrial automation component provided by ABB. The following is detailed information and features about the processor module:

General information:

Part number: 3BHE013299R0002

Protocol: ABB module bus

Line redundancy: Yes

Module redundancy: Yes

Heat exchange: Yes

Used with HI controller: not

Vertical or horizontal installation: both available

Detailed information:

Connector: Agile, HP like, multifunctional link, 24V power supply type.

ModuleBus current distribution: fiber optic interface, one transmission interface, and one receiving interface for high values.

10 mbit wavelength: 650 nm

Power dissipation: 0.5 watts

Environment and Certification:

Temperature, operation: Horizontal installation at 55 C (131 F), vertical mounting at 40 C (104 F)

Temperature, storage: -25 C (-13 F) to+70 C (158 F)

Equipment class: Class I

Entrance protection: IP20

CE marking: Yes

Dangerous location: Class 1 Zone 2, ATEX Zone 2

Naval Certificate: ABS BV、DNV-GL、LR

RoHS compliance: Directive 2011/65/EU (en 5081:2012)

WEEE Compliance: Directive 2012/19/EU

Size and weight:

Width: 17.6 millimeters (0.69 inches)

Height: 56.7 millimeters (2.23 inches)

Depth: 42.3 millimeters (1.67 inches)

Weight: 90 grams (0.20 pounds)

Modular busbar optical connection:

It is the communication interface between CI801 or CI840/CI840A FCI and tb820/tb820 v2/tb840/tb840.

Modular busbars are connected to data machines in I/O clusters or ABB drives through fiber optic modular busbars.

Other features:

This processor module supports ABB's industrial automation solutions and is compatible with ABB's other industrial automation products.

Due to its high reliability and stability, this processor module is widely used in various industrial environments, including energy, construction, transportation, and infrastructure.

Product image
