Product Details Introduction

SDCS-PIN-48-SD Pulse Transformer Board

The SDCS-PIN-48-SD pulse transformer board is one of the key components designed specifically for the ABB frequency converter series, used for motor speed feedback and speed monitoring. It has the following main characteristics and functions:

Accurate speed feedback: Provide high-precision speed feedback signals to ensure the accuracy of motor speed monitoring.

Pulse transformer technology: Using pulse transformer technology, the speed information of the motor is converted into pulse signal output.

Strong adaptability: Compatible with various ABB frequency converter series, including DCS500, DCS600, and ACS600, with strong applicability.

Reliable performance: sturdy design, suitable for industrial environments, with high reliability and stability.

Easy installation and connection: Provides a simple and easy-to-use installation method, reducing deployment complexity and time costs.

technical specifications

Pulse output: usually in different specifications such as 2 pulses/revolution or 10 pulses/revolution.

Power supply voltage: generally 24VDC.

Working temperature range: usually between -10 ° C and+50 ° C.

Size: Standard size design for easy installation in ABB frequency converters.

application area

Industrial drive: used to monitor and control the speed and operating status of industrial motors.

Automation system: Used for speed feedback and closed-loop control in automation control systems.

Mechanical manufacturing: suitable for speed monitoring and control of various mechanical equipment and production lines.

advantage

High precision: Provides precise speed monitoring to ensure the stability and reliability of system operation.

High reliability: The sturdy design is suitable for industrial environments, ensuring long-term stable operation.

Easy to install: Provides a simple installation method, reducing deployment time and cost.

Strong compatibility: Compatible with various ABB frequency converter series, it has strong flexibility and applicability.

Product image
