Product Details Introduction

The NI PCIe-6321 data acquisition device is a high-performance data acquisition device produced by National Instruments (NI). The following is a detailed introduction to the data acquisition instrument:

1. Main features

High speed data acquisition: The NI PCIe-6321 data acquisition instrument supports high-speed data acquisition with a sampling rate of up to 250 kS/s, which can meet the requirements of real-time monitoring and control.

Multi channel data acquisition: This data acquisition instrument provides 16 analog inputs and can simultaneously collect multiple signals and data.

High precision: The analog input resolution is 16 bits, with an input range of ± 10 V, ensuring the accuracy and precision of data collection.

2. Functional configuration

Analog Input/Output: In addition to 16 analog inputs, NI PCIe-6321 also has 2 analog outputs with an output rate of 900 kS/s and an output range of ± 10 V.

Digital I/O: The device includes 24 digital I/O lines (8 of which are 1 MHz hardware timing lines), suitable for reading and controlling digital signals, such as switches, triggers, etc.

Counter/Timer: Provides 4 channels of 32-bit counters/timers, capable of generating pulse signals, measuring pulse frequency, etc.

3. Performance parameters

Dedicated bandwidth: up to 250 MB/s dedicated bandwidth, ensuring efficient data transmission in various applications.

Interface optimization: The local PCI Express interface has been optimized to have excellent throughput and low latency characteristics, further improving the efficiency and accuracy of data collection.

4. Software support

NI-STC3 timing and synchronization technology: Provides advanced features such as independent analog and digital timing engines, and repeatable measurement tasks.

Programming software support: supports LabVIEW for National Instruments LabWindows/CVI、 Or other programming software, allowing users to easily write, debug, and execute data collection and control programs.

5. Application areas

The NI PCIe-6321 data acquisition instrument is suitable for various real-time monitoring and control applications, such as laboratory measurement, industrial automation, testing and measurement, and other fields. It is also an ideal choice for 42V automotive applications, radar, sonar, and ultrasound.

Product image
