Product Details Introduction

The Schneider MDI1PRD23B7-EQ servo motor module is a high-performance product of Schneider Electric, mainly used in industrial automation systems to achieve precise motion control and positioning applications. The following is a detailed introduction to this module:

Main features and functions:

Servo motor control: The MDI1PRD23B7-EQ servo motor module can control the motion of the servo motor, achieving precise position control, speed control, and torque control.

Communication interface: The module may have multiple communication interfaces, such as Ethernet, serial port CAN bus, etc., facilitate communication and data exchange with the control system.

Encoder feedback: Supports encoder feedback, enabling real-time acquisition of motor position and speed information, and closed-loop control of the motor based on feedback information to ensure more accurate motion control.

Protection function: Built in multiple protection functions, such as overload protection, overheating protection, overcurrent protection, etc., to protect the motor and driver from damage.

Flexible configuration: With flexible configuration options, it can be customized and configured according to specific application requirements, including control parameters, communication protocols, etc.

Reliability and stability: High reliability and stability, capable of stable operation under various industrial environmental conditions, and with a long service life.

Technical parameters:

Efficiency: An efficiency greater than 90% means that most of the energy can be effectively utilized during the energy conversion process, reducing energy waste.

Working temperature range: A wide range of working temperatures, from -20 ° C to+50 ° C, suitable for various industrial application scenarios.

Processing capability: Equipped with a 32-bit RISC processor, it has excellent processing speed and stability, ensuring precise and efficient operation of servo motors.

Input/output parameters: The input voltage range is 12-48VDC, the output voltage is 5VDC, and the maximum output current is 10A.

Size and weight: The size is 170mm x 105mm x 32mm, and the weight is approximately 120g.

Application scenario:

The MDI1PRD23B7-EQ servo motor module is suitable for various industrial applications that require high-precision motion control, such as automation equipment, robots, CNC machine tools, etc.

Product image
