EMERSON HD22010-3 DC screen charging module
Product Details Introduction
The EMERSON HD22010-3 DC screen charging module is a charging device designed specifically for power systems and industrial control systems. The following is a detailed introduction about the charging module:
Features and functions:
Efficient Charging: The HD22010-3 charging module is designed to quickly and efficiently charge batteries or supercapacitors in DC power systems.
Adjustable charging parameters: With adjustable charging parameters, such as charging current, charging voltage, etc., to meet the charging needs of different batteries or supercapacitors.
Protection functions: including overcurrent protection, overvoltage protection, reverse current protection, etc., to ensure the safety and reliability of the charging process.
Communication interface: Supports communication interfaces, such as Modbus, for easy communication and monitoring with other control devices.
Application field:
Power system: In the power system, The HD22010-3 charging module is used to charge the backup battery pack in the DC power supply system, ensuring continuous power supply in case of grid failure or power outage.
Industrial control system: In industrial control systems, this module is used to charge backup batteries or supercapacitors in industrial equipment, ensuring that the system can continue to operate or safely shut down in the event of a power outage.
Transportation: In the field of transportation, The HD22010-3 charging module can be used to charge battery packs in electric vehicles or rail transit systems, extending battery life and improving the reliability of vehicle operation.
Energy storage: In an energy storage system, this module is used to charge batteries or supercapacitors in the energy storage system, balance energy supply and demand, and improve energy utilization efficiency.
Technical specifications and details:
Heat dissipation method: A combination of self cooling and air cooling is used for heat dissipation, which operates under light load and self cooling, in line with the actual operation of the power system.
Protection function details:
When the input voltage is less than 313 ± 10Vac or greater than 485 ± 10Vac, the module is protected and there is no DC output.
When the output voltage is greater than 325 ± 5Vdc, the module is protected and there is no DC output, which needs to be manually restored.
When the output voltage is less than 198 ± 1Vdc, the module alarms and there is a DC output.
It also includes functions such as short circuit retraction, phase loss protection, over temperature protection, and primary overcurrent protection.
Structure and Design: Adopting an aluminum alloy die-casting mold shell, with built-in CPU distributed control mode, stable and reliable operation.
Certification and standards: Certified according to CE safety regulations, electromagnetic compatibility standards, and industry product type inspections.
In summary, The EMERSON HD22010-3 DC screen charging module has broad application prospects in the field of power supply due to its high efficiency, high stability, wide application range, and convenient maintenance.
Product image
