Product Details Introduction

The IC694ALG392 analog output module is an important component of the PACSystems RX3i series produced by General Electric (GE) in the United States. The following is detailed information and features about this module:

Main functions:

Mainly used for analog output, it can convert digital signals into analog signal outputs to achieve control over external devices or systems.

Technical specifications:

Number of channels: With 8 analog output channels, each channel can control an independent analog signal.

Output range: Supports output of voltage and current, including voltage/current and 8-channel output types. The input range includes 0 V to+10 V, -10 V to+10 V, 0-20 mA, and 4-20 mA.

Resolution: The resolution of the module is 16 bits, which ensures the accuracy of the analog output signal.

Speed: The output speed is 8ms, ensuring fast response of the signal.

Current consumption: 110 mA @ 5 VDC (or user provided 24 VDC), which is the current required for the module to operate.

Certification and Protection:

This module has been certified by multiple certification bodies, including UL UL HAZLOC, Zone 2 CE, ATEX C1D2, ABS, BV, DNV, GL, KRS, LR, etc. ensure the safety and reliability of the modules.

Has a certain level of protection to protect it from environmental conditions such as humidity, temperature, and vibration.

Application scope:

Widely used in the field of industrial automation, especially in systems that require precise control of analog output.

It has been widely used in various industries such as CNC machinery, metallurgy, oil and gas, papermaking and printing, textile printing and dyeing, electronic manufacturing, automobile manufacturing, tobacco, plastic machinery, power plants, water treatment/environmental protection, municipal engineering, steel mills, cement plants, robots, and rail transit.

Programming environment:

Integrating programming with PLC, motion control, and human-machine interface (HMI) into a unified environment provides users with a more convenient programming experience. This combination helps to reduce learning cycles and research and development time, and improve production efficiency.

Other features:

May have diagnostic functions for monitoring module status and reporting any faults or abnormal situations.

Designed for integration with GE's PLC (Programmable Logic Controller) system to achieve analog signal output control of external devices.

Overall, The IC694ALG392 analog output module is a powerful, flexible, and widely used industrial automation product that can meet various analog output needs.

Product image
