AI815 3BSE052604R1 Analog Input Module

AI815 3BSE052604R1 Analog Input Module

Product Details Introduction

The AI815 3BSE052604R1 analog input module is an equipment produced by ABB for industrial automation systems. The following is a detailed summary of the main characteristics and information of this module:

Product Overview:

The AI815 3BSE052604R1 analog input module belongs to ABB's AC 800M series process control system, which is used to convert various physical quantities (such as voltage, current, temperature, etc.) into digital signals for processing and monitoring by computers or control systems.

Main features:

Multi signal type support: Supports multiple signal types, such as 0-20 mA, 4-20 mA, 0-10V, and 0-5V, suitable for various industrial automation environments.

High precision measurement: Through high-precision analog input circuits, analog signals can be accurately converted into digital signals, providing accurate data support for control systems.

High reliability: By using high-quality electronic components and advanced production processes, the module ensures high reliability and stability, and can operate stably in various complex and harsh industrial environments.

Easy to integrate: Using standard interfaces and communication protocols, it is easy to integrate with other devices and systems, achieve data sharing and exchange, and improve system efficiency.

Flexible configuration: It can be flexibly configured according to actual needs, and users can choose different signal types, input ranges, resolution and other parameters to meet different application needs.

Easy maintenance: With comprehensive fault diagnosis and alarm functions, it can provide timely alarm prompts when faults occur, making it convenient for users to troubleshoot and maintain. At the same time, it provides convenient replacement and maintenance interfaces, reducing maintenance costs and difficulties.

Technical parameters:

Signal specifications: Supports signal types such as 0-20 mA, 4-20 mA, 0-10V, and 0-5V.

Number of channels: With multiple input channels, it can monitor multiple physical quantities simultaneously.

Resolution: It may have a resolution of 12 bits or higher to ensure the accuracy of the data.

Input impedance: 290k Ω for voltage input and 230-275k Ω for current input.

Work environment:

Working temperature: -10-70 ℃ (wide temperature optional).

Relative humidity: ≤ 90% (non condensing).

Storage temperature: -40~80 ℃.

Test certification:

Complies with IEC61000-4 series standards, including ESD RS, EFT, Surge, CS, and MS tests ensure the stability and reliability of the equipment in various electromagnetic environments.

Mechanical characteristics:

External dimensions: 132mm105mm52mm.

Shell: IP30 protection level, corrugated aluminum reinforced casing.

Installation method: 35mm DIN rail installation.

Net weight: 800g.

in summary, The AI815 3BSE052604R1 analog input module is a powerful, stable, easy to integrate and maintain industrial automation product, widely used in various industrial automation systems, providing accurate and reliable analog signal input support for control systems.

Product image
