HONEYWELL FC-TSHART-1620M Universal Interface Module
Product Details Introduction
The product features of the HONEYWELL FC-TSHART-1620M universal interface module can be clearly summarized as follows:
Communication and interface characteristics:
Support the predetermined communication rate specified in the standard specifications, meeting various rate requirements, such as 9.6kBit/s to 12MBit/s.
The data electrical interface adopts a 9-pin Sub-D socket connector, which complies with the protocol specifications of Profibus DP.
Support the Profibus DP bus standard to ensure compatibility with various industrial automation systems.
Power supply and protection:
Adopting a dual power redundant input design, the voltage range is DC9-36V, with a typical value of DC24V and a power consumption of less than 4W.
Equipped with DC1500V voltage isolation and reverse protection function, enhancing the stability and safety of the power supply.
Lightning protection and overcurrent protection:
The electrical interface has a lightning protection capability of 4000V, effectively preventing damage to equipment caused by lightning.
Provide 1.5A overcurrent protection and 600W surge protection functions to ensure the long-term stable operation of the interface module.
Display and alarm:
Equipped with 6 dual color LED status indicator lights, real-time display of equipment working status, convenient for users to quickly determine the location of faults.
Provide power failure relay output alarm function, once a power failure is detected, an alarm signal can be output through the relay.
Design and Certification:
Adopting industrial grade design and undergoing EMC testing certification, it ensures stable operation in various industrial environments.
IP30 protection level, providing a certain degree of dust protection.
Power supply and installation methods:
Support DC9-36V wide redundant dual power supply to ensure the reliability of power supply.
Adopting the standard industrial 35mm guide rail installation method, it is easy to install and maintain on site.
Other features:
Support manual setting of all standard rates or rate adaptation for dial switches (all electrical interfaces have the same rate).
Suitable for industrial automation control systems, it can control the working status of various equipment and sensors, achieving automated production and management.
In summary, the HONEYWELL FC-TSHART-1620M universal interface module plays an important role in industrial automation control systems due to its rich communication interfaces, powerful power and protection capabilities, complete display and alarm functions, industrial level design and certification, flexible power supply and installation methods, and other characteristics.
Product image
