VM600 CMC16 200-530-025-014 Status Monitoring Card

VM600 CMC16 200-530-025-014 Status Monitoring Card

Product Details Introduction

The VM600 CMC16 200-530-025-014 status monitoring card is a high-performance status monitoring system component designed specifically for the VM600 series status monitoring systems (CMS). The following are the detailed features and functions of the status monitoring card:

Core features:

As the core component of the VM600 series status monitoring system, this monitoring card is responsible for data collection, analysis, and result transmission.

Used in conjunction with VM600 CMS software, it works through VM600 series CPU M modules with Ethernet controllers or directly through serial links.

Input/output characteristics:

The input is fully programmable and can accept multiple signal types, including speed, phase reference, vibration (acceleration, velocity or displacement), dynamic pressure, air gap rotor, and pole profile.

The signal can be input from adjacent mechanical protection cards (MPC 4) through the VM600 "raw bus" and "Tacho bus", or externally through the threaded terminal connector on the IOC 16T.

Data processing capability:

The onboard processor is responsible for acquisition and control, conversion from time domain to frequency domain (Fast Fourier Transform), frequency band extraction, unit conversion, limit checking, and communication with the host system.

Each channel supports 10 available frequency bands, including RMS, peak, true peak, true peak to peak, and other configurable frequency bands.

Support the measurement of signals such as acceleration (g), velocity (inches/second, millimeters/second), and displacement (mils, micrometers), and can convert units according to requirements.

Alarm and monitoring:

When the value exceeds one of the six configurable limits, exceeds the rate of change alert, or deviates from the stored baseline, an event is generated.

Support adaptive monitoring technology, which can dynamically adjust alarm set points based on machine parameters such as speed and load.

Technical specifications:

Model: CMC16 200-530-025-014

Measurement range: may be related to specific application scenarios, but generally covers a wide range of vibration frequencies.

Resolution: may vary depending on specific configuration and application requirements.

Accuracy: 1% of reading

Number of channels: 16

Communication method: Supports communication protocols such as RS485 and Modbus.

Working temperature range: -40 ° C to 70 ° C

Protection level: IP30

Application field:

This status monitoring card is suitable for multiple industries such as industrial automation, mechanical manufacturing, textile machinery, packaging machinery, printing machinery, food processing, logistics, etc.

Through the introduction of the above characteristics, it can be seen that the VM600 CMC16 200-530-025-014 status monitoring card is a powerful and flexible configuration component of the status monitoring system, which can meet the needs of various industrial applications.

Product image
