MPS022 SCHROFF power module

MPS022 SCHROFF power module

Product Details Introduction

The MPS022 SCHROFF power module is a feature rich power solution, and the following is detailed information about this module:

Product features:

Active Power Factor Correction (PFC): This power module has an active power factor correction function, which can effectively improve the waveform of input current, reduce harmonic interference, improve power factor, and thus enhance power efficiency.

Wide input voltage range: The MPS022 SCHROFF power module supports a wide input voltage range, which can fluctuate between 90 to 264VAC or 130 to 350VDC, demonstrating strong adaptability.

Low interference characteristic: The module has the characteristic of low interference, with ripple less than 10mVPP, which can significantly reduce the impact on other devices.

Integrated decoupling diode redundancy operation: By integrating decoupling diode redundancy operation, this module increases the stability and reliability of the system.

Technical specifications:

Power supply: Although the specific power is not specified in the reference article, the power capacity of the power supply module can usually be selected based on device requirements, and different modules may have different power ranges.

Voltage and current: The power module may support different voltage input ranges to adapt to power standards in different regions. Meanwhile, it usually has stable output voltage and current to ensure the normal operation of the equipment.

Current protection: Some power modules may have overload protection and short circuit protection functions to protect the equipment from the effects of excessive current or short circuits.

Heat dissipation: In order to maintain appropriate temperature during operation, some power modules may be equipped with a heat dissipation system.

EMI/EMC compliance: The power module needs to comply with electromagnetic interference (EMI) and electromagnetic compatibility (EMC) standards to ensure that it does not cause interference to other devices.

Installation method: The installation method of the MPS022 SCHROFF power module may be embedded or desktop, depending on the requirements of the actual application scenario.

Physical properties:

Size: The height of the power module is 6U, the width is 8,12 HP, and the depth is 171.93mm (the circuit board depth is 160mm).

Handle: The module may be equipped with a front panel with a handle for easy installation and movement.

Connector: Use H 15 M connectors (2 pieces) and coding strips (2 pieces, installed).

AC/DC conversion: The MPS022 SCHROFF power module involves AC/DC conversion, which converts AC power into DC power to meet the power requirements of the equipment. The power flow can be bidirectional, including two forms: rectification and active inversion.

Application scenario: This power module is suitable for various industrial control systems and redundant systems, and can meet various power demands and environmental requirements.

In summary, the MPS022 SCHROFF power module has become a high-performance and reliable power solution due to its wide input voltage range, active power factor correction, low interference, flexible installation methods, and rich physical characteristics.
