RET670 1MRK002816-AB Digital Protection Relay
Product Details Introduction
RET670 1MRK002816-AB Digital Protection Relay Manual
1、 Product Overview
RET670 1MRK002816-AB is a digital protection relay produced by ABB, designed specifically for power systems and industrial automation applications. It provides fast and selective protection, monitoring, and control functions, suitable for various equipment such as two winding and three winding transformers, autotransformers, step-up transformers, and power generation transformer groups.
2、 Main features
High precision measurement: using advanced digital signal processing technology, it can accurately measure electrical parameters such as current and voltage, ensuring the accuracy of protection operations.
Quick response: With fast response speed, it can quickly cut off the faulty circuit when a fault occurs, prevent the fault from expanding and equipment damage, reduce power outage time, and reduce the risk of equipment damage.
Multifunctional protection: Provides multiple protection functions, such as overcurrent protection, undervoltage protection, overvoltage protection, ground fault protection, etc., to meet the needs of different electrical equipment and motors.
Flexible Configuration: Supports flexible configuration and programming, allowing users to set functions and adjust parameters through the software, and customize personalized protection plans.
Remote monitoring and control: Supports remote monitoring and control functions, allowing operators to remotely monitor the status of the power system and perform necessary operations.
3、 Technical parameters
Rated voltage: 110kV
Rated current: 1A
Protection range: overvoltage, undervoltage, overcurrent, differential protection
Operation time: ≤ 20ms
Relay accuracy: 0.5%
Working temperature range: -40 ° C to+70 ° C
Shell material: plastic
Installation method: DIN rail installation
4、 Application field
RET670 1MRK002816-AB digital protection relay is widely used in the following fields:
Transformer protection in power systems
power plant
transformer substation
industrial enterprise
building
5、 Product advantages
High reliability: By adopting mature technology and strict manufacturing processes, it can ensure long-term reliable operation.
Improving safety: Effectively reducing transformer failure rate and improving the safety and stability of the power system.
Improving efficiency: can increase the utilization rate of transformers and reduce operating costs.
Reduce maintenance costs: simple structure and convenient maintenance.
6、 Installation and debugging
When installing and debugging the RET670 1MRK002816-AB digital protection relay, please follow the relevant safety regulations and operating procedures to ensure that the equipment is installed correctly and operates reliably.
7、 Operation and Maintenance
Users can perform various operations and function selections through an intuitive and user-friendly interface. At the same time, it is recommended to regularly maintain the equipment, including cleaning, tightening screws, inspecting cables, etc., to ensure the long-term stable operation of the equipment.
Product image
