Bently 350093135785-01 System Display Screen
Product Details Introduction
Bently 350093135785-01 System Display Manual
1、 Product Overview
The Bently 350093135785-01 system display screen is a local or remote visual display device designed specifically for Bently Nevada's 3500 series mechanical protection systems. Its design fully complies with the requirements of the American Petroleum Institute (API) standard 670 and can comprehensively display all key information of the 3500 mechanical protection system.
2、 Main functions
Display content:
System Event List
Alarm Event List
All channel, monitor, relay module, key position sensor module or tachometer module data
Configuration method:
Use 3500 rack configuration software for configuration, making it easy for users to customize display content according to their actual needs.
3、 Installation method
The system display screen supports the following four installation methods:
Front installation: Install directly on the front panel of a full-size 3500 rack using a dedicated hinge bracket, facilitating access to the rack's buffered output connectors, as well as user interface buttons and switches.
19 inch EIA rack installation: The monitor is mounted on a 19 inch EIA rail and maintains a distance of 100 feet from the 3500 mini rack (up to 4000 feet when using external power).
Panel Installation: The monitor is installed in a panel opening located in the same cabinet or up to 100 feet away from the 3500 system (up to 4000 feet away when using an external power supply).
Independent installation: The monitor is flush with the wall or panel and can be installed up to 100 feet away from the 3500 system (up to 4000 feet when using an external power source).
4、 Environmental requirements
Working temperature: -30 ° C to+65 ° C (-22 ° F to+150 ° F)
Storage temperature: -40 ° C to+85 ° C (-40 ° F to+185 ° F)
Humidity: 95%, non condensing
5、 Specification parameters
Dimensions: 241.3 mm x 24.4 mm x 241.8 mm (9.50 inches x 0.96 inches x 9.52 inches)
Weight: 0.82 kilograms (1.82 pounds)
6、 Summary
The Bently 350093135785-01 system display screen, as an important component of the 3500 series mechanical protection system, not only provides comprehensive visual display functions, but also has high flexibility and adaptability to meet monitoring needs in different industrial scenarios. Meanwhile, its stable and reliable performance and excellent environmental adaptability also ensure its normal operation in various harsh environments.
