BENTLY 3500/92 136180-01 Communication Gateway I/O Moduler

Product Details Introduction

BENTLY 3500/92 136180-01 Communication Gateway I/O Module Manual

1、 Product Overview

BENTLY 3500/92 136180-01 is a communication gateway I/O module produced by Bently Nevada and belongs to its 3500 series. This module has extensive communication capabilities and can integrate monitoring data and status of all frameworks with process control and other automation systems, achieving efficient data transmission and processing.

2、 Main features

Communication capability:

Supports Ethernet TCP/IP and serial (RS232/RS422/RS485) communication protocols to connect with various systems and devices.

Supports communication protocols such as Modicon Modbus (via serial communication) and Modbus/TCP (serial Modbus variant for TCP/IP Ethernet communication).

Supports Bently Nevada proprietary protocols and seamlessly integrates with 3500 rack configuration and data acquisition software packages.

Module configuration:

Provide configurable Modbus register functionality, providing the same functionality as the initial value register.

The front panel LED status indicator includes OK LED and TX/RX LED, which respectively indicate the module's operating status and communication status.

Physical parameters:

Dimensions (height x width x depth): 241 mm x 24.4 mm x 242 mm.

Weight: 0.82 kilograms.

Power consumption: Typical values are 5.0 watts (for Modbus RS232/RS422 I/O modules) and 5.6 watts (for Modbus RS485 I/O modules).

Network connection:

Connect to the 10BASE-T star topology Ethernet network through the RJ45 interface to achieve high-speed data transmission.

Security:

The functional safety level reaches SIL 2.

3、 Function Description

Data collection:

Collect data from other modules in the framework using a high-speed internal network, including current measured values with timestamps, module status, and current alarm status.

The data type and refresh time depend on the channel configuration and module type, but the data collection rate for all modules in the 3500 framework will not exceed 1 second.

System integration:

Integrate the monitoring data and status of the framework with process control and other automation systems through Ethernet TCP/IP and serial communication protocols.

Supports Ethernet communication with 3500 rack configuration software and data acquisition software.

4、 Installation and Maintenance

Installation:

Please follow the installation instructions provided by the manufacturer to ensure that the module is installed in the correct position and securely secured.

Maintenance:

Regularly check the working and communication status of the module to ensure that the LED indication is normal.

If you need to replace the module or perform other maintenance operations, please follow the maintenance manual and guidelines provided by the manufacturer.

5、 Precautions

During installation and use, please comply with relevant safety regulations and operating procedures.

Avoid causing excessive impact or vibration to the module, as it may affect its performance and lifespan.
