CI871AK01 3BSE092693R1 Communication Interface Module
Product Details Introduction
CI871AK01 3BSE092693R1 Communication Interface Module Manual
1、 Product Overview
CI871AK01 3BSE092693R1 is a PROFINET IO communication interface module produced by ABB, aimed at achieving efficient PROFINET IO communication functions. This module fully utilizes the four core advantages of Intel processors, improves the performance and determinacy of real-time applications, and provides a stable and reliable data transmission solution for industrial automation applications.
2、 Main features
High performance data transmission:
CI871AK01 3BSE092693R1 is capable of transmitting data at the microsecond level, ensuring real-time monitoring and control.
Supports data transmission speeds of up to 12 Mbps, meeting the data transmission speed requirements of industrial automation applications.
Wide device compatibility:
This module can control and monitor various devices and parameters, such as sensors, valves, motors, etc., to achieve precise control of industrial processes.
Supports PROFINET IO V2.3 and V2.4 standards to ensure compatibility with multiple PROFINET IO devices.
Fault detection and reporting:
Having the ability to automatically detect and report faults can help reduce maintenance and downtime, and improve production efficiency.
Durable and sturdy design:
By obtaining CE certification and UL508 certification, we ensure the high quality and reliability of our products.
A sturdy and durable interface solution that can adapt to various industrial environments.
Easy to configure and manage:
Support SNMP management, making it convenient for users to remotely configure and manage modules.
Equipped with a built-in web server, providing an intuitive configuration and diagnostic interface.
3、 Technical specifications
Size and weight:
Dimensions: 127.5 x 186 x 59 mm
Weight: 0.7 kg
Power and environmental parameters:
Power consumption: 15 W
Working temperature: 0 ° C to 60 ° C
Storage temperature: -40 ° C to 85 ° C
Connection and communication:
Connect to PROFINET IO devices via Ethernet.
Support redundant ring networks to improve system reliability and stability.
4、 Typical applications
CI871AK01 3BSE092693R1 expansion unit module is suitable for ABB Ability ™ The System 800xA ® control system is widely used in fields such as factory automation, machine control, and process control. Through this module, users can achieve seamless connection with PROFINET IO devices, improving system integration and operational efficiency.
5、 Installation and Maintenance
Please follow the installation instructions provided by the manufacturer and ensure that relevant safety regulations and operating procedures are followed during maintenance. If you have any questions or need further assistance, please contact ABB's technical support team.
6、 Precautions
During installation and use, please ensure compliance with all applicable safety regulations and operating procedures.
Avoid causing excessive impact or vibration to the module, as it may affect its performance and lifespan.
Before performing any maintenance or component replacement, please ensure that the module is completely shut down and disconnected from power.
Product image
