Molex APP ETH PCU-C PCU2000 ETH Network Interface Card Manual

1、 Product Overview

Molex APPETH-PCU-C PCU2000ETH is a network interface card designed specifically for Ethernet communication. It supports TCP/IP protocol, provides a data transfer rate of 10/100 Mbps, and is suitable for PCI 3.3/5V bus. This network interface card complies with RoHS standards, ensuring environmental protection and sustainability.

2、 Main features

High speed communication: Supports 10/100 Mbps Ethernet communication, meeting most network communication needs.

Strong compatibility: Compatible with PCI 3.3/5V bus, suitable for various computer and server systems.

Easy to install: Designed with standard PCI slots, installation is simple and fast.

High reliability: Made with high-quality materials and exquisite craftsmanship, ensuring long-term stable operation.

3、 Technical specifications

Interface type: Ethernet interface, compliant with IEEE 802.3 standard.

Transmission rate: 10/100 Mbps (automatic negotiation).

Interface quantity: 1 Ethernet port, RJ45 connector.

LED indicator: 4 LED indicator lights, displaying TX, RX, link, and 100 Mbps status respectively.

Bus support: PCI version 2.2, 32-bit, 33 MHz PCI universal 3.3V/5V keying, PCI-X compatible.

Memory specification: 16 MB SDRAM, supports hardware Plug&Play (32 bytes per board).

Work environment:

Working temperature: 0 ° C (32 ° F) to+65 ° C (149 ° F).

Storage temperature: -40 ° C (-40 ° F) to+85 ° C (185 ° F).

Safety standards: comply with EN55022 Class B, EN61000-6-2, EN61000-3-2, EN61000-3-3 and other standards.

4、 Application field

Network communication equipment: can be used for network communication equipment such as routers, switches, gateways, etc., providing efficient data transmission and processing capabilities.

Industrial automation and control: In the industrial field, it can be used for tasks such as control systems, monitoring equipment, data acquisition and processing, to improve production efficiency and quality.

Internet of Things (IoT): In the field of IoT, it can be used to connect and control various smart devices, such as smart homes, smart cities, smart health devices, etc.

Data center and server: In the field of data center and server, it can be used to handle and manage large amounts of data streams, virtualization technology, security features, etc.

Embedded systems: can be used to build various embedded systems, such as embedded controllers, embedded computers, embedded sensors, etc.

5、 Installation and Maintenance

Installation: Please follow the installation guide provided by the manufacturer to ensure that the network interface card is correctly inserted into the PCI slot and securely secured.

Driver installation: Install the corresponding driver program so that the operating system can recognize and use the network interface card.

Maintenance: Regularly check the working status of the network interface card to ensure that the LED indicator lights are displayed normally. If any problems are found, please contact technical support in a timely manner for resolution.

Product image
