Product Details Introduction

MOOG G122-824A002 servo amplifier is a high-performance and high-precision control equipment. The following is a detailed analysis of its characteristics:

Product Overview:

MOOG G122-824A002 is a servo amplifier produced by MOOG, specifically designed for industrial applications that require precise control and monitoring.

This amplifier adopts the unique design concept and manufacturing process of MOOG, ensuring its excellent performance and reliability.

Main features:

High performance: Adopting advanced electronic technology and algorithms, it can efficiently process various data and control instructions, improve the response speed and operational efficiency of the system.

Closed loop control: suitable for closed-loop applications that require proportional and/or complete amplifiers, capable of achieving precise closed-loop control.

User friendly: Featuring a user-friendly front-end panel with LED and test points, it facilitates user settings and control.

Multiple input methods: Supports multiple input methods, including single ended input, scalable zero differential input and gain differential input, as well as feedback sensor excitation, to meet different application requirements.

High reliability: Using high-quality materials and manufacturing processes, it can operate stably for a long time in harsh working environments, ensuring the reliability and stability of industrial automation and control systems.

Flexible configuration options: With flexible configuration options, it can be customized according to different application requirements, including channel configuration, communication interface selection, and control algorithm implementation.

Technical parameters:

Model: G122-824A002

Type: Servo amplifier

Input signal type: usually analog or digital signal, depending on configuration

Control accuracy: High precision, ensuring the accuracy of fluid control

Working environment conditions: The range of working temperature, humidity, etc. depends on specific needs

Application field:

This servo amplifier is widely used in industrial fields that require high-precision fluid control, such as aerospace, machine tools, plastic machinery, metallurgy, and testing equipment.

Installation and maintenance:

When installing, it is recommended to use curled "boot strap grommets" as screw terminals, leaving enough cable length so that the circuit card can be removed from the housing while the wires are still connected.

In terms of current parameters, the recommended nominal value is 24V DC and 22 to 28V without load 75mA@24V At load 200mA@100mA .

The radiation emitted by this amplifier is much lower than the level specified in the CE marking test, but it is still necessary to pay attention to the use of shielded cables and appropriate grounding measures when wiring to reduce external interference.

In summary, the MOOG G122-824A002 servo amplifier is a high-performance, high-precision, user-friendly, and reliable device that can meet the needs of various industrial application scenarios that require precise control and monitoring.

Product image
