UAD149A1501 3BHE014135R1501 High Performance I/O Function Module

Product Details Introduction

User Manual for UAD149A1501 3BHE014135R1501 High Performance I/O Function Module

1、 Product Overview

UAD149A1501 3BHE014135R1501 is a high-performance I/O functional module designed specifically for industrial control and other applications. This module provides high-performance I/O functionality, including 8-bit DIO, LPC, and SMBus, as well as rich interface options, aimed at creating more energy-efficient factory equipment.

2、 Main features

High performance I/O: UAD149A1501 3BHE014135R1501 provides high-performance I/O functionality, meeting the high requirements for data transmission and processing in industrial control and other fields.

Rich interfaces: This module is equipped with 8 USB 2.0 ports, 6 PCIe x1 slots, 4 PCI slots, and 1 IDE interface, supporting diverse external device connection requirements.

Low power design: A low-power module design that conforms to COM Express R2.0 Type 2, fully utilizing the AMD A55E controller hub to optimize energy consumption.

Advanced computing and graphics performance: Not only does it perform efficiently in data processing, but it also supports excellent graphics functionality, making it suitable for industrial control applications that require graphics processing capabilities.

Power outage protection system: As an I/O power outage protection system, it ensures the safety of data and the stability of equipment in the event of power failure.

3、 Technical specifications

Interface: 8 USB 2.0, 6 PCIe x1, 4 PCI, 1 IDE

Controller: AMD A55E Controller Hub

I/O types: 8-bit DIO, LPC, SMBus

Power requirements: It is necessary to follow the power requirements of the module to ensure stable system power supply

Heat dissipation management: Although designed for low power consumption, attention should still be paid to heat dissipation in high load applications

Compatibility: Supports COM Express R2.0 Type 2 interface, requires confirmation of compatibility with the system motherboard

4、 Precautions for use

Compatibility confirmation: Before installation, it is necessary to confirm the compatibility between the module and your system motherboard (carrier board).

Power supply requirements: Check and comply with the power supply requirements of the module to ensure stable system power supply.

Heat dissipation management: In high load applications, appropriate heat dissipation solutions may be needed to maintain long-term stable operation.

Firmware and driver updates: Regularly check and update the firmware and drivers of modules to achieve optimal performance and address potential security issues.

Installation and wiring: Follow the correct installation steps and electrical safety regulations to ensure that all interfaces and connectors are installed correctly and securely.

Environmental conditions: Confirm that the usage environment (temperature, humidity, dust, etc.) is within the operating range of the module.

5、 Application field

The UAD149A1501 3BHE014135R1501 high-performance I/O function module is widely used in industrial automation, robotics technology, medical equipment, packaging, and printing equipment, providing high-performance and reliable I/O solutions for these fields.
