PCD235C101 3BHE057901R0101 Expansion Adapter

PCD235C101 3BHE057901R0101 Expansion Adapter

Product Details Introduction

PCD235C101 3BHE057901R0101 Expansion Adapter Manual

1、 Product Overview

PCD235C101 3BHE057901R0101 is an expansion adapter designed specifically for industrial automation systems, used to connect and expand various devices and modules. It has multiple interfaces, including digital input/output interfaces, analog input/output interfaces, Ethernet interfaces, etc., to meet the needs of different industrial applications.

2、 Product features

Interface extension: PCD235C101 3BHE057901R0101 has rich interfaces that can easily connect and expand various devices and modules in industrial automation systems.

Module Communication: This adapter supports communication and data exchange between different modules, enabling collaborative work among various components within the system.

Signal conversion: PCD235C101 3BHE057901R0101 has a signal conversion function, which can convert and adapt different types of signals to meet the interface requirements of various devices in the system.

Reliability: As an industrial grade equipment, this adapter has high reliability and stability, and can operate stably for a long time in harsh working environments.

Flexibility: This adapter has a certain degree of flexibility and can be customized and expanded according to specific application requirements to meet the needs of different scenarios.

3、 Technical specifications

Digital input/output: Supports 12 digital control inputs, compatible with 24V or 48V; Provide 16 relay outputs for controlling external devices.

Analog Input/Output: Supports 3 analog inputs with a range of+/-10V or+/-20mA; Provide 3 analog outputs with a range of+/-10V.

Temperature sensor interface: Supports 3 PT100 or PTC temperature sensor interfaces.

Other interfaces: including RS485 interface for communication with other devices; Optical module interface, supporting 3 optical links for data transmission; Isolation bending machine relay interface, used to connect with the bending machine relay.

System control indicator lights: Provide 4 indicator lights for monitoring system status.

Working temperature range: -25 to+70 ° C, suitable for various environments.

4、 Application field

The PCD235C101 3BHE057901R0101 expansion adapter is widely used in industrial automation, power systems, transportation and other fields, to connect and expand various industrial equipment and modules, and achieve system function expansion and upgrading.

5、 Installation and Maintenance

Installation: Use the provided template to drill standard holes and install them without the need for special tools. This adapter can be clipped onto the back of the panel or installed on DIN rails using a local expansion adapter.

Maintenance: Regularly check the connection and working status of the adapter, keep it clean, and avoid dust, oil, and other factors that may affect its performance. If replacement or repair is required, please contact the product supplier or professional technical personnel.

6、 Precautions

Please ensure to follow the instructions in the product manual during installation and use.

Do not use in environments beyond the rated operating range of the adapter to avoid damaging the adapter or affecting the accuracy of measurement results.

Product image
