VMIVME-1150 Optocoupled Digital Input Board

VMIVME-1150 Optocoupled Digital Input Board

Product Details Introduction

VMIVME-1150 Optical Coupled Digital Input Board Manual

1、 Product Overview

VMIVME-1150 is a 64 bit optical coupled digital input board designed and optimized specifically for VME buses. It provides 64 optically coupled digital inputs, featuring high isolation, flexibility, low cost, and high noise resistance. This circuit board is suitable for industrial applications that require high reliability and density, such as testing and measurement systems, data acquisition systems, industrial control systems, and machine vision systems.

2、 Product features

High isolation: Provides a continuous voltage of 1.000 V and a pulse voltage of 7.500 V, effectively ensuring the safety of the system.

Input range: Supports an input range of 5 V to 48 VDC, suitable for different voltage requirements.

Filter input options: Filter input can be selected as needed to improve signal quality.

Dual I/O connector: Provides dual I/O connectors for easy connection with external devices.

Contact closure sensing: Supports contact closure sensing to ensure the accuracy of signal transmission.

Voltage or current input options: You can choose the appropriate input source type according to the application scenario.

Positive or negative real input options: Supports positive or negative real input to meet different logic level requirements.

High reliability: Made with high-quality components to ensure the high reliability of the circuit board.

3、 Technical specifications

Number of input ports: 64 optically coupled digital input terminals

Input range: 5 V to 48 VDC

Isolation degree: 1.000 V continuous voltage, 7.500 V pulse voltage

Data transmission type: Supports 8-bit or 16 bit data transmission

Access permissions: Non privileged or supervised I/O access permissions

Access time: maximum 250 millimicroseconds

Size: Double Eucar exterior dimensions with front panel

4、 Installation and Configuration

Board address: The circuit board address is selected by the onboard DIP switch and can run in any available slot on the VME bus backplane except for slot 1.

VME bus access: The address modifier bit is decoded and supports short supervised or non privileged short I/O access.

VME bus reply: DTACK reply is a response to data gating (DS0 or DS1) and decoded board address.

5、 Application field

VMIVME-1150 optical coupled digital input board is widely used in various industrial fields, such as testing and measurement systems, data acquisition systems, industrial control systems, and machine vision systems. It provides an 8-byte digital input port with high reliability, density, and noise resistance, helping users achieve precise signal transmission and control.

Product image
