VMIVME2170A Digital Output Module

VMIVME2170A Digital Output Module

Product Details Introduction

VMIVME2170A Digital Output Module Manual

1、 Product Overview

VMIVME2170A is an optical isolated digital output module designed and optimized specifically for VMEbus. It provides 32 optical isolated outputs with high output voltage tolerance, high isolation potential, and flexible data transmission methods, making the module widely used in industrial automation, data acquisition, and control systems.

2、 Main features

32 optical isolated outputs: providing stable digital signal output, effectively isolating external interference.

Output voltage and current range: With an output capacity of 2.5mA to 300mA, external pull-up voltage is provided to achieve maximum isolation.

Configurable pull-up resistor: can be configured on-site according to requirements, providing greater flexibility.

High output voltage tolerance: can reach 30V in normal mode, ensuring stable operation in various environments.

High isolation potential: Provides a 1kV continuous, 6kV pulse isolation potential to effectively protect subsequent circuits.

Flexible data transmission: Supports 8-bit or 16 bit data transmission, as well as two types of data transmission methods: supervised and non privileged.

Dual Eurocard format: PC board with dual Eurocard dimensions for easy installation and integration.

3、 Technical specifications

Number of output channels: 32 channels

Output current range: 2.5-300A

Output voltage tolerance: up to 30V

Isolation potential: 1kV continuous, 6kV pulse

Data transmission method: 8-bit or 16 bit

Size: Double European card size

4、 Installation and Configuration

Insert the VMIVME2170A module into the corresponding slot on the VMEbus backplane.

Configure DIP switches on the board according to actual needs and set the board address.

Connect the external power supply to ensure that the module is working properly.

Data transmission and control are carried out through VMEbus.

5、 Application field

The VMIVME2170A digital output module is widely used in industrial automation, data acquisition and control systems, testing and measurement equipment, and other fields, providing stable and reliable digital output signals for various application systems.

Product image
