SHINKAWA VM-5C SST-2194-001-P001G Redundant Servo System

SHINKAWA VM-5C SST-2194-001-P001G Redundant Servo System

Product Details Introduction

SHINKAWA VM-5C SST-2194-001-P001G Redundant Servo System Manual Summary

1、 Product Overview

The SHINKAWA VM-5C SST-2194-001-P001G redundant servo system is a monitoring solution designed specifically for critical applications, aimed at providing precise monitoring of large rotating machinery such as turbines. The system integrates 16 monitoring units, which can comprehensively cover key state parameters such as vibration, displacement, and speed, ensuring the stable operation of the equipment.

2、 System characteristics

Redundant design: The system adopts a redundant design, and when the main monitor fails, the backup monitor can immediately take over, ensuring the continuity of monitoring and the reliability of data.

High precision: By utilizing advanced sensing and processing technology, this system can provide high-precision monitoring data to help users detect abnormal equipment situations in a timely manner.

Widely applicable: This system is suitable for various types of large rotating machinery equipment, such as electric motors, pumps, fans, compressors, etc.

3、 Technical specifications

Monitoring parameters: including key parameters such as vibration, axial position, eccentricity, and expansion difference.

Measurement range: The specific range depends on the equipped sensor, but the system supports a wide range of measurement requirements.

Output signal: Provides analog and digital outputs, facilitating user integration into existing monitoring systems.

Alarm Settings: Supports multiple alarm settings, including over limit alarms and trend alarms, to help users prevent potential faults.

4、 System composition

Monitoring unit: core component responsible for data collection, processing, and output.

Relay module: used to control the output of alarm signals and protect equipment.

Power supply unit: provides stable power supply to the system.

Instrument rack: used for installing and fixing various components, available in multi unit types (VM-5H4, VM-5W2) and single unit types (VM-5G).

5、 Input sensor

The system supports multiple sensors, such as FK/VK series, CV/CA series, LVDT, RD series, MS series, etc., to meet different measurement needs. These sensors provide signals to the VM-5 series monitors to ensure the accuracy and reliability of data.

6、 Alarm and Notification

When the device malfunctions, the system can immediately issue an alarm notification. The alarm output supports multiple modes, such as danger, alarm, normal, etc., making it convenient for users to configure according to different needs. At the same time, the system also supports integration with other monitoring systems to achieve remote monitoring and notification functions.

7、 Work environment

Working temperature: 0 to 65 ° C (32 to 149 ° F)

Storage temperature: -30 to+85 ° C (-22 to+185 ° F)

Relative humidity: 20 to 95% RH (non condensing)

Product image
