Product Details Introduction

SHINKAWA VM-5N SST-2194-001-P001G Redundant Servo System Manual Summary

1、 Product Overview

SHINKAWA VM-5N SST-2194-001-P001G redundant servo system is a high-performance and highly reliable monitoring and control solution. The system ensures continuity and stability in critical applications through redundant design, and is widely used in various industrial fields that require high-precision and high reliability monitoring.

2、 Main features

Redundant design: The system adopts a redundant design to ensure that in the event of a failure of the main monitor, the backup monitor can immediately take over, ensuring the continuity of monitoring and the reliability of data.

High precision: Adopting advanced sensing and processing technology, providing high-precision monitoring data to help users detect abnormal equipment situations in a timely manner.

Easy to integrate: The system provides multiple output signals, making it convenient for users to integrate into existing monitoring systems.

User friendly: equipped with an intuitive display interface and easy-to-use interface, making it easy for users to set up and view data.

3、 Technical specifications

Monitoring range: The specific range depends on the equipped sensor, but the system supports a wide range of measurement requirements.

Output signal: Provide analog output (such as 1 to 5VDC, 4 to 20mADC) and digital output to meet the integration requirements of different systems.

Alarm Settings: Supports multiple alarm settings, including H-Danger (100% monitor range), H-Alarm (90% monitor range), L-Alarm (10% monitor range), and L-Danger (0% monitor range).

Temperature range: Working temperature from 0 to 65 ° C (32 to 149 ° F), storage temperature from -30 to+85 ° C (-22 to+185 ° F).

Display interface: LCD digital instrument and LCD bar graph instrument (40 segments, with backlight), displaying both measured values and alarm set values.

4、 System composition

The SHINKAWA VM-5N SST-2194-001-P001G redundant servo system consists of the following main components:

Main monitor: responsible for the main monitoring tasks, real-time collection and processing of data.

Backup monitor: In the event of a malfunction in the main monitor, take over monitoring tasks to ensure continuity of monitoring.

Sensor: Used to convert physical quantities into electrical signals for the monitor to process.

Display interface: used to display monitoring data and alarm information.

5、 Installation and debugging

Installation location: A well ventilated, non corrosive gas and dust free environment should be selected for installation.

Wiring requirements: Follow the wiring diagram in the product manual to ensure the correctness and reliability of the wiring.

Debugging steps: After the system installation is completed, follow the debugging steps in the product manual to ensure the normal operation and performance of the system.

6、 Maintenance and upkeep

Regular inspection: Regularly check the operation status and connection lines of the system to ensure its stability and reliability.

Cleaning work: Regularly clean the system to remove dust and dirt, and maintain the cleanliness and heat dissipation performance of the system.

Product image
