SHINKAWA VM-5Y1-02GEM Relay Module Unit

Product Details Introduction

SHINKAWA VM-5Y1-02GEM Relay Module Unit Manual

1、 Product Overview

SHINKAWA VM-5Y1-02GEM is a high-performance relay module unit designed specifically for applications that require precise control and protection. This module has multiple functions and characteristics, which can meet the needs of different industrial fields.

2、 Main features

Alarm indication:

Danger alarm (red LED): indicates a serious malfunction or dangerous situation.

Alarm (yellow LED): indicates that the device is in an abnormal working state and needs attention.

ALLMINICATOR OK (green LED): indicates that the system is working properly.

Bypass indicator:

At 25 ° C, the bypass error is F S. 0.5% ±; At 0 to 65 ° C, the bypass error is F S. 2.0%.

Specification parameters:

Recorder output (from the rear panel): Provides voltage or current output proportional to the monitor, ranging from 1 to 5VDC (output impedance: 250 Ω) and 4 to 20mADC (maximum load resistance: 500 Ω).

Alarm setting range: Allow setting within 10 to 110% of the monitor range.

Alarm setting accuracy: ± F S. 1.0% or lower.

Alarm setting repeatability: ± F S. ± 0.1% or lower.

Input signal:

The input signal of the monitor is output through a buffer amplifier, with signal levels ranging from -0.8 to -22VDC (VK) and 0 to 5VDC (VC).

Alarm output:

Provide alarm outputs with 3 points (danger, alarm, normal) or 4 opinions (danger, alarm, OK1, OK2), with H and L being or outputs.

Temperature range:

Working temperature: 0 to 65 ° C (32 to 149 ° F).

Storage temperature: -30 to+85 ° C (-22 to+185 ° F).

Measurement display:

Using LCD digital instrument (5-digit) and LCD bar graph instrument (40 segments with backlight) to display both measured values and alarm set values simultaneously.

Materials and Finishes:

The panel is made of aluminum material and meets Munsell N-4.0 (equivalent) standards.

3、 Function Introduction

Relay module functions:

Through the relay module, it is possible to control the on and off of the high-voltage power supply by low voltage (such as 5V, 9V, 12V, 24V).

Security:

The module design has the function of preventing misoperation, ensuring the stable operation of the system.

Wiring and installation:

The module provides high current wiring terminals for easy wiring without the need for welding.

4、 Installation and debugging

Installation location: Please install in a well ventilated, dust-free, and corrosion-free environment.

Wiring: Please follow the wiring diagram in the product manual to ensure accuracy.

Debugging: After the system installation is completed, please follow the debugging steps in the product manual to debug and ensure that the system is working properly.

5、 Maintenance and upkeep

Regular check: Please regularly check the operation status and connection lines of the system to ensure its stability and reliability.

Cleaning work: Regularly clean the system to remove dust and dirt, and maintain the cleanliness and heat dissipation performance of the system.

6、 Precautions

Do not use this module in working environments that exceed the product specifications.

When installing, debugging, maintaining, and maintaining, please be sure to follow the operating procedures and safety precautions in the product manual.
