Product Details Introduction

SHINKAWA VM-5Y1-02/GEM 1594-005-P001G Monitor Manual Summary:

1、 Product Overview

The SHINKAWA VM-5Y1-02/GEM 1594-005-P001G monitor is a high-performance and high-precision industrial monitoring device designed specifically for monitoring the condition of large rotating machinery. It can monitor key parameters such as vibration, displacement, and speed of equipment in real time, and provide intuitive monitoring results and alarm information through LED indicator lights, LCD digital instruments, and LCD bar graph instruments.

2、 Main features

Accurate monitoring: By using high-quality sensors, precise monitoring of equipment parameters such as vibration, displacement, and speed can be achieved.

Multiple alarm settings: Provides various alarm settings such as H-danger, H-alarm, L-alarm, L-danger, etc., to meet different safety monitoring needs.

LED indicator light: It adopts red, yellow, and green LED indicator lights to visually display the operating status and alarm information of the equipment.

LCD display: LCD digital instrument and LCD bar graph instrument simultaneously display measured values and alarm set values, making it convenient for users to view at any time.

Flexible configuration: Different racks and power units can be selected according to needs to achieve flexible system configuration.

3、 Technical specifications

Monitor range: Depending on specific configuration and sensors, but typically supports a wide range of measurement requirements.

Alarm setting range: can be set within 10% to 110% of the monitor range.

Alarm setting accuracy: ± F S. 1.0% or lower to ensure the accuracy of alarms.

Alarm setting repeatability: ± F S. ± 0.1% or lower to ensure the stability and consistency of alarm settings.

Monitor output: Provides voltage or current output proportional to the monitor, ranging from 1 to 5VDC (output impedance: 250 Ω) and 4 to 20mADC (maximum load resistance: 500 Ω).

Working temperature: 0 to 65 ° C (32 to 149 ° F), ensuring stable operation in various industrial environments.

4、 Installation and debugging

Installation location: A well ventilated, dust-free, and corrosion-free environment should be selected for installation.

Wiring: Please follow the wiring diagram in the product manual to ensure accuracy.

Debugging: After the system installation is completed, please follow the debugging steps in the product manual to debug and ensure that the system is working properly.

5、 Maintenance and upkeep

Regular check: Please regularly check the operation status and connection lines of the system to ensure its stability and reliability.

Cleaning work: Regularly clean the system to remove dust and dirt, and maintain the cleanliness and heat dissipation performance of the system.

6、 Precautions

Do not use this monitor in working environments that exceed product specifications.

When installing, debugging, maintaining, and maintaining, please be sure to follow the operating procedures and safety precautions in the product manual.

Product image
